CK Worldwide MT375 AC/DC TIG Welding Power Source

CK Worldwide MT375 AC/DC TIG Welding Power Source

The MT375-AC/DC is the answer to both creativity and production driven TIG welding. This innovative water cooled TIG welding system provides the ability to quickly and efficiently adapt to dynamic welding situations, while maintaining the same quality of experience you have come to expect from CK Worldwide.

The MT375AC/DC is a dual voltage powerful 375 amp inverter with; AC balance and frequency, post gas flow settings, and pulse settings that use analog dials allowing for ease of use and range.

With background testing performed by production welders and the best TIG welding professionals in the industry the MT375 delivers precision welding.

Package Includes:

• MT375 AC/DC Welding Machine

Machine Specifications

230V: 44 Amps / 26 Amps

230V: 5275 Amps DC; 5260 Amps AC

460V: 5375 Amps DC; 5360 Amps AC

230V: 10200 Amps DC

460V: 10300 Amps DC

230V:275 Amps @ 21.0 VDC, 35% duty cycle

260 Amps @ 20.4 VAC, 35% duty cycle

460V:375 Amps @ 25.0 VDC, 35% duty cycle

360 Amps @ 24.2 VAC, 35% duty cycle

230V: 200 Amps @ 28.0 VDC, 40% duty cycle

460V: 300 Amps @ 32.0 VDC, 40% duty cycle

Full Product Brochure
