Description:
Pro Installer Insulated Studs – Single 8 mmPro Installer Insulated studs are available in single and twin stud versions, featuring8 mm (5/16″) and 10 mm (3/8″) variants. A double stud version with 10 mm and 8 mmstuds is also included for extending outboard motor cables. The Power Tapping Platesingle stud models provide convenient termination points for additional small cables.Pro Installer family features are replicated with these insulated studs, generousstud length, modular footprint, insulating covers with label recess, and commoninterconnection height.Specifications:• Power tapping plate: 4x 4 mm (5/16″) terminals• Maximum current through power tapping plate: 50A per terminal (4x 50A maximum)• Note: no power passes through the stud so no amp rating is given 50V DC• High temperature, fiber reinforced plastic base provides strength and chemical resistance• Clear polycarbonate cover with snap-out extra cable access• Stainless steel studs, screws and nuts for longevity in the marine environment• Insert moulded studs with metric threads• Double studs feature ‘snap out’ insulating partition, to allow linking of studs
