Norco 76503A 3 Ton Bottle Jack
It is ideal for heavy-duty trucks, agriculture, construction, mining, mobile homes, oil fields, automotive, and marine applications where lifting, pushing, spreading, bending, pressing, or straightening are required.
| Low Lift Height | 7.5″ |
| High Lift Height | 15.5625″ |
| Stroke | 5.25″ |
| Screw Extension | 2.8125″ |
| Base Size | 4″ x 4.5625″ |
| Carry Handle | No |
| Shipping Weight | 8 lbs. |
Features:
- Two-piece zinc-plated handle
- Rust prevention with “Parkerized” pump piston, ram, and extension screw
- Leak-proof “Uniweld” construction
- State-of-the-art design reduces repair time
- Longer wear life due to internally machined oil passages, smooth bearing surfaces, and close tolerances.
- Lightweight forged base provides strength where needed
- Heavy-duty extension screw and release valve designed to eliminate parts and reduce breakage and excessive wear
- Safety bypass and overload systems prevent cylinder damage and ensure compliance with ASME/PASE load-limiting standards
